Swimming Pool-Heat Pump Solutions
How the copeland heat pump makes a difference
heating a swimming pool during low ambient conditions can consume a lot of electricity: leading to high energy bills. You can improve your swimming pool's heating efficiency by installing an energy efficient pool heat pump.
These are typically sized to match the average heat loss from a swimming pool, therefore the initial warm up times are likely to be longer.once the initial temperature is achieved, heat pumps will maintain the pool temperature to compensate for the evaporative & other heat losses . throughout the entire swimming season and beyond. copeland heat pumps maintain the disired water temperature efficiently at a significantly lower cost.
| Parameters | Commercial Heat Pump Heating | Solar | Electric Heating | LPG | Diesel |
| Energy savings w.r.t conventional | Up to 85% | 60-75% | N.A | N.A | N.A |
| Space Requirement | 5% of Solar | N.A | 5% of Solar | 5% of Solar | 5% of Solar |
| Climate Independent | Yes | No | N.A | N.A | N.A |
| Efficiency | Up to 400% | Up to 95% | Up to 95% | Up to 80% | Up to 80% |
| Maintenance | Minimal | Panel Cleaning | High | Moderate | High |
| Environment Friendly | Yes | Yes | Yes | No | No |
| Safety | Yes | Yes | Moderate | No | Moderate |
| Depreciation | 40% in 1st Year | 40% in 1st Year | No | No | No |
Technical Details
| Pool Size | 30m3 | 50m3 | 100m3 | ||
| Model Name | EHP-Z004k-TEP/TBP-001 | EHP-Z008K-TEP/TBP-001 | EHP-Z017K-TEP/TBP-001 | ||
| Power Supply | 380V/50Hz/3ph | ||||
| Operating Ambient Temp. | 0C | 0 to 43 | |||
| Max Water Temperature | 0C | 35 | |||
| Capacity | Kw | 13 | 22 | 43 | |
| Input Power | Kw | 2.6 | 4.4 | 8.6 | |
| Water Heating | COP | - | 5.0 | ||
| Max.Input Current | A | 5 | 7.6 | 21 | |
| Refrigerant Gas | - | R22/R407C | |||
| Compressor | Type | - | Scroll/ZW | Scroll/ZW | ZW Scroll |
| Quantity | pcs | 1 | 1 | 2 | |
| Fan Motor | Supply | Volt/ph. | 230V/50Hz/1ph | ||
| Heat Exchanger | Type/Model | - | Titanium Tube | ||
| Inlet Pipe Size | mm/Inch | 50/2" | |||
| Water Piping | Outlet Pipe Size | mm/Inch | 50/2" | ||
| Min.Water Flow | LPH | 3800 | 7300 | 16500 | |
| Max.Water Flow | LPH | 4600 | 9200 | 18000 | |
| Dimensions | Dimension (DxWxH) | mm | 490*1140*810 | 710*1216*995 | 710*1250*1335 |
| Approx. Weight | Kg | 110 | 180 | 250 |
